Maiz Dryer With Multiple Fuel Burners
PRINCIPLES OF MAZIE DRYER
The grain enters the grain dryer from the top through the elevator and the input scraper conveyor, and automatically falls into the grain storage layer by gravity for short-term storage. The bottom of the grain storage layer is directly connected with the grain scattering layer. When the grain dryer is working, the grain scattering plate of the grain scattering layer will evenly scatter the grain into the drying layer. At the same time, the burner furnace generates heat by burning fuel (rice husk, straw, firewood, biomass particles, coal, gas, etc.), and passes through the heat ex-changer to heat and dry the fresh and clean air from the air inlet of the grain dryer. The dry air enters the drying layer of the grain dryer, contacts the grain evenly and effectively, takes away the moisture in the grain, and then exits the dryer through the powerful fan. The grains in the drying layer continue to fall, and then lifted by the elevator and enter the grain dryer continuously. Until the internal moisture detector detects that the moisture content of the grain reaches the preset value, the grain dryer will automatically stop working to complete the drying of a batch of grain.and then transport the grain to the dry barn for storage through the outlet conveyor.
GROUP WORKING FLOW OF MAZIE DRYER
MAIN FEATURES OF MAZIE DRYER:
1. Low-Temperature Circulation Drying
The drying is fast and efficient, greatly reduced grain breakage rate
2. Compatible With Multiple Fuel Burners
Workable with furnace of husk, straw, firewood, biomass materials, coal, gas to reduce cost
3. Automatic Intelligent Detection
Intelligent moisture detector, high-precision sensor control, automatic operation and shutdown, saving labor costs
4. Even Drying
Adopt stainless steel grain scatter plate, quantitative feeding, strict control of grain temperature and humidity, to achieve uniform of drying
5. Powerful Fan
Diagonal flow large-scale high-efficiency fans ensures large air volume and high efficiency
6. Durable And Wear-Resistant Material
Adopt high-quality stainless steel and carbon steel guarantees the wear resistance and service life of the grain dryer.
7. Indirect Heat Exchange System
The air intake system of the grain dryer and the heat ex-changer of the burner adopt indirect contact to ensure uniform and controllable airflow temperature while avoiding toxic and harmful gases from contacting the grain.
PARAMETERS OF MAZIE DRYER:
APPLICATIONS:
Paddy,Wheat,Corn,Maize,Sorghum,Sunflower Seeds,Beans,etc
FREQUENTLY ASKED QUESTIONS FOR MAZIE DRYER:
1. How to get the right type grain dryer for me?
To get the fast and best answer,we need to confirm:
A. what kind material you want to dry?
B. What is moisture percentage of your material %?
C. How many tons per hour of the capacity you need?
D.What type of fuel you want for the dryer?
E. Do you have the budget to purchase of our drying machine?
2. How long it will be to get the dryer machine after paid?
It is 20-30 working days depends on situation. Holidays or peak sales season may be slow.
3. Do you have the warranty for your machine?
Yes,we have warranty for our machine for 1 year. You can also buy an additional warranty period.
During the warranty period of our dryer machine,we will send the parts to our user for total free.If out of warranty,we will charge a reasonable fee for the parts.
4. Do you supply other equipment,like Moisture Meter,Conveyor,Fan,Temperature sensor ?
Yes,it is standard equipment,which will be send together with our dryer machine.
5. It is safe to use your machine?
Yes. Our dryer machine is equipped with overload device,temperature control system,control fuse,leakage protection device,air pressure switch. Also our dryer machine air inlet is indirect contact with the fire of the furnace.
6. It is necessary to send an engineer to help us for guidance of installation and modify the machine?
Usually no need. it is easy to install our dryer machine.we will also guide you online.
If you still need engineer.you need to pay visa,round trip airplane tickets,accommodation,food,and extra salary of our engineer,etc.
